Factory Price Sell 3N 50nm 99.9% Indium Tin Oxide Powder

Short Description:

  • CAS No.: 50926-11-9
  • Molecular Formula: In2O5Sn
  • Quality Standard: 99.9% 99.99%
  • Minimum Order: Depends on your requirement
  • MW: 428.34
  • Melting point: 287℃
  • Boiling point: 82 °C
  • Density: 1.2 g/mL at 25 °C(lit.)
  • Refractive index: n20/D 1.5290-1.5460(lit.)
  • Fp: 57.2 °F
  • Storage temp.: -20°C
  • Water Solubility: Insoluble in water.
  • ACGIH: TWA 0.1 mg/m3
  • NIOSH: TWA 0.1 mg/m3

Product Detail

Product Tags

氧化铈1
Anhui-Fitech-Materials-Co-Ltd- (23)
Anhui-Fitech-Materials-Co-Ltd- (24)

Basic information:

ITO nano ultrafine powder prepared by high-frequency plasma gas-phase combustion method, the product has high purity, low bulk density (40% lower than similar products in China), and it is easy to be dispersed into stable nano-paste. Nano ITO powder has good conductivity and transparency, can cut off the harmful electronic radiation, ultraviolet and far infrared. Therefore, after spraying on glass, plastic and electronic display, it can cut off the harmful electronic radiation, ultraviolet and infrared IR and electrostatic shielding coatings and anti-counterfeit inks while enhancing the conductivity and transparency. Nano indium tin oxide powder is an N-type oxide semiconductor - indium tin oxide, nano ITO powder film that indium tin oxide semiconductor transparent conductive film, usually has two performance indicators: resistivity and light transmittance. In the oxide conductive film, to Sn-doped In2O3 (ITO) film with high transmittance and good conductivity, and easy to etch a fine pattern in the acid. One of the transmittance rate to reach more than 90%, nano ITO powder in its transmittance and resistance value by the proportion of In2O3 and Sn2O3 to control, usually Sn2O3: In2O3 = 1:9.

Specification

Item Purity APS SSA Color Morphology Mass Ratio Dispersity
ZY-ITO30 99.99% 30nm 40.74m2/g Green grey body-centered Cubic In2O3:SnO2=90:10 no hard agglomeration, can be dispersed in various liquids

Application:

1.Nano indium tin oxide powder is mainly used to produce transparent conductive coatings for liquid crystal displays, flat panel displays, plasma displays, touch panels, electronic ink and so on.

2.ITO nanopowder is also used for various optical coatings, infrared-reflecting coatings (hot mirrors) for architectural, automotive, and sodium vapor lamp glasses are mostly used.

3.Indium Tin Oxide nanoparticles have been used as conductive material in plastic electroluminescent lamp.

4.Nano ITO powder can be used to make thin film strain gauges which can operate at temperatures up to 1400 °C and can be used in harsh environments, e.g. gas turbines, jet engines, and rocket engines

Storage Conditions

Nano ITO should be sealed in vacuum and stored in cool and dry room and it should not be exposure to air. In addition, the product should be avoided under stress.

氧化铈3

Certificate

The products have been approved by FDA,REACH,ROSH,ISO and other certification, in line with national standards.

b7d457348c43fdbc460183dbae04cf7
950c4aec877e06940eb739c44c856c0
02edcb14670b02c8cb087d00580860c
55b32e9848a2d16a8c1bc72070f10df
5892ef06491e4769dde29fc3e034c95

Advantage
Quality First
Competitive Price
First-class Production Line
Factory Origin
Customized Services

hjgfyut
hgfdduyt
gfhduty

Factory

factory (4)
factory (3)
factory (2)
factory (1)

Packing

1kg/ bag; 25kg/ barrel;
20 tons/1×20‘FCL Shipment.

Packing-1-Cobalt-powder_副本
Packing-1-Cobalt-powder_副本
Packing-1-Cobalt-powder_副本

FAQ:
Q: Are you trading company or manufacturer ?
A: We are factory.

Q: How long is your delivery time?
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but do not pay the cost of freight.

Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
